General Specialties S-SOP-S Side-of-Pole Mount for 2 Small to Medium Solar Modules

The General Specialties S-SOP-S Side-of-Pole Mount is designed to support two small to medium-size solar modules on a vertical pole.

This Model S mount accommodates two modules measuring up to 59.5 × 26.5 in each and provides an adjustable tilt range from 20° to 90°. The self-aligning channel cross pieces help simplify installation while creating a strong, stable connection to the mounting pipe.

Mounting pipe is not included.

Features

• Fits Two Small to Medium Solar Modules: Designed for two modules measuring up to 59.5 × 26.5 in each.
• Adjustable Tilt: Module inclination can be adjusted from 20° to 90° by changing the brace attachment point.
• Self-Aligning Cross Pieces: Channel cross pieces align to the pipe to help reduce installation time and provide a strong mounting foundation.
• Flexible Brace Positioning: Braces can be installed forward of the modules or behind them to accommodate different site layouts.
• Standard 3 in Pipe Compatibility: Designed for 3 in Schedule 40 or Schedule 80 pipe.
• 4 in Pipe Option Available: A version for 4 in Schedule 40 or Schedule 80 pipe can be special ordered.
• Made in the USA: Manufactured in the United States by General Specialties.

Specifications

Model: S-SOP-S
Module Capacity: 2 Small to Medium-Size Solar Modules
Maximum Module Size: 59.5 × 26.5 in each
Maximum Array Surface Area: 22 sq. ft.
Rail Length: 58 in
Brace Length: 58 in
Tilt Range: 20° to 90°
Standard Pole Size: 3 in Schedule 40/80 Pipe
Optional Pole Size: 4 in Schedule 40/80 Pipe, Special Order

Installation Notes

Pipe is not included.

The cross pieces are designed to remain fixed once installed, while module tilt is adjusted using the brace attachment points. This allows seasonal or site-specific angle changes without repositioning the main mounting hardware.
