The Victron Energy Quattro 48/3000/35-50/50 combines a true sine wave inverter, an adaptive battery charger, and automatic AC source switching in a single system. The Quattro can accept two independent AC inputs and automatically connect to the active source.
Advanced features include adaptive charging, PowerAssist technology, dual AC inputs, dual AC outputs, parallel operation for increased power, and split-phase and three-phase system capability.
When paired with a compatible GX device, such as the Cerbo GX, the Quattro can be monitored and controlled locally or remotely through Victron Energy’s VRM platform. Users can access system information and controls from a phone, tablet, laptop, or desktop computer. Remote functions can include system monitoring, inverter settings, and automatic backup generator control.
Victron Energy is one of the leading manufacturers of renewable energy systems and has earned an outstanding reputation for technical innovation, reliability, and quality. The company has served the off-grid, industrial, vehicle, commercial marine, and recreational marine markets for more than 45 years.
The Quattro Series of inverter/chargers is IEC listed.
Pure sine wave inverter
Adaptive battery charging technology
Dual AC inputs with automatic source selection
Dual AC outputs
PowerAssist technology
Power factor corrected charger
Split-phase and three-phase capability
VE.Bus communication for remote monitoring and control
Compatible with GX devices and Victron VRM monitoring
Low total harmonic distortion of less than 2%
Parallel operation of up to six units
Up to 18kVA output with six units operating in parallel
Nearly instantaneous transfer relay for uninterrupted power
Five-year limited warranty
Nominal DC Input Voltage | 48VDC
DC Input Voltage Range | 38–66VDC
Nominal AC Output Voltage | 120VAC ±2%
Continuous Output Power | 3000W
Battery Charger Output | 35A
AC Inputs | 2
AC Outputs | 2
Communication Interface | VE.Bus
Certification | IEC listed
Unit Weight | 43 lb
Shipping Weight | 48 lb
Dimensions | 11.6 × 17.3 × 13 in
