MidNite Solar 20A 600VDC DIN Rail Breaker

The MidNite Solar MNEPV20-600-4PP is a four-pole, polarized DC circuit breaker rated for 20A and 600VDC. It is designed for DIN rail mounting and indoor renewable energy applications.

MidNite Solar breakers are designed to interrupt their full rated load at the rated voltage repeatedly without damage when properly installed and applied.

Always use a properly sized breaker for circuit protection and disconnecting.

Features

• 20A Current Rating: Designed for compatible DC circuits requiring 20A overcurrent protection.
• 600VDC Rating: Suitable for high-voltage DC applications up to its rated voltage.
• Four-Pole Design: Provides four poles in a single DIN rail-mounted breaker.
• Polarized Breaker: Proper polarity must be observed during installation.
• DIN Rail Mounting: Designed for convenient installation in compatible breaker enclosures.
• Wide Wire Range: Accepts conductors from 14 to 6 AWG.
• Type 1 Environmental Rating: Intended for indoor applications.

Specifications

Model: MNEPV20-600-4PP
Current Rating: 20A
DC Voltage Rating: 600VDC
Number of Poles: 4
Polarity: Polarized
Wire Size Range: 14 to 6 AWG
Terminal Torque: 20 in-lb / 2.3 N·m
Width: 2 in / 52 mm
Environmental Rating: Type 1 / Indoor
Mounting: DIN Rail

Warranty

Warranty: Five-Year Warranty
